VP

-xx

-F

Ax (1、2、3）

-x

Series code

VP-08

VP-12

VP-15

VP-20

Nominal flow (displacement)

L/min(1800rpm)

Mounting style

Flange mounting

Operating pressure range

A1: 8~35 kgf/cm²

A2: 30~55 kgf/cm²

A3: 50~70 kgf/cm²

Connection type

无标记：平键轴芯 轴径12.7㎜

No mark:shaft diameter 12.7㎜

DH：9齿花键

DH：9 tooth spline

XH:7齿花键

XH:7 tooth spline

D：轴径15.875㎜

D; shaft diameter 15.875㎜

B：扁轴

B: flat shaft

VP

-xx

-F

Ax (1、2、3）

-x

Series code

VP-30

VP-40

Nominal flow (displacement)

L/min(1800rpm)

Mounting style

Flange mounting

Operating pressure range

A1: 8~35 kgf/cm²

A2: 30~55 kgf/cm²

A3: 50~70 kgf/cm²

Connection type

无标记：平键轴芯 轴径19.05㎜

No mark:shaft diameter 19.05㎜

DH：9齿花键

DH：9 tooth spline
